- Double-cylinder Motar pump
Model No.:
AMP60/50Price:
Pls contact us.Minimum Order:
1
Product Abstract:
Wanna get a FREE quote now? Just click the below FREE QUOTE button. The experts will get back to you as soon as possible.
- Product Description
- AMP60/50 Double-cylinder Product Abstract:1. Type: Double-cylinder Motar pump2. Brand: iAEG3. Model: AMP60/504. Output: 60L/min, piston type: doubleAMP60/50 Double-cylinder single-acting motar pump introduce and applications:The RH15W plaster machine has the hose pump as the conveying unit and the min. oilless aircompressor as the unit supplying the compressed air.The RH15W plaster machine has the hose pump as the conveying unit and the min. oilless aircompressor as the unit supplying the compressed air.The RH15W plaster machine has the hose pump as the conveying unit and the min. oilless aircompressor as the unit supplying the compressed air.? Shotcrete/concrete spraying/gunite for tunnels,hydro-power engineering?mines?un -derground engineering, civil engineering and slope stabilization,etc.? Artificial soil seeding for no soil surface, such as rock, sand, and for no fertility soil surface.mortar pump is suitable for pumping and spraying the wet ready-mixed mortar witch is pumpable, such as Cement mortars, Lime plasters, Gypsum plasters, Masonry mortars, Insulating plasters, Self-leveling floor screeds, etc.mortar pump is suitable for pumping and spraying the wet ready-mixed mortar witch is pumpable, such as Cement mortars, Lime plasters, Gypsum plasters, Masonry mortars, Insulating plasters, Self-leveling floor screeds, etc.mortar pump is suitable for pumping and spraying the wet ready-mixed mortar witch is pumpable, such as Cement mortars, Lime plasters, Gypsum plasters, Masonry mortars, Insulating plasters, Self-leveling floor screeds, etc.mortar pump is suitable for pumping and spraying the wet ready-mixed mortar witch is pumpable, such as Cement mortars, Lime plasters, Gypsum plasters, Masonry mortars, Insulating plasters, Self-leveling floor screeds, etcmortar pump is suitable for pumping and spraying the wet ready-mixed mortar witch is pumpable, such as Cement mortars, Lime plasters, Gypsum plasters, Masonry mortars, Insulating plasters, Self-leveling floor screeds, etc.AMP60/50 mortar pump is a double-cylinder single-acting piston pump, with the advantages of compact structure, reliable operation, low fault rate, convenient cleaning and maintenance, and high-pressure pump etc. It is mainly applied for tunnel, mining project, dam, foundation engineering of big bridge and high-rise building, and the different kinds of underground engineering etc.AMP60/50 Double-cylinder single-acting motar pump Features:· Directional-control ball valve· Hydraulic drive· Double-cylinder single-acting· Integrate pump head and hopper; prevent eduction and deposition together with the paddle agitating· Compact structure, convenient for maintainingAMP60/50 Double-cylinder single-acting motar pump Technical Data:
Cylinder Dia φ90 mm Cylinder 2 Output 60 L/min Rated Working Pressure 5 Mpa (50bar) Piston stroke 145 mm Piston Speed 82 /min Inlet diameter 75 mm Outlet diameter 50 mm Max.Aggregate.size 5 mm Cement : Sand ≥1:3 Conveying Dist. 50-120 m Hopper Volume 160 L Power unit 7.5 Kw Transmission Fluid drive Dimension 1950×1150×1150 mm Weight 800 kg A.E.G motar pump has the following different types:Plaster Machine AMP-15W;Piston motar pump includes Single piston motar pump AMP50/40 and double-cylinder motar pump AMP60/50;Dry-mixed motar spraying machine AMP-30D;Wet-mixed motar spraying machine AMP-30W and AMP-38W.
