- Single piston Motar pump
Model No.:
AMP50/40Price:
Pls contact us.Minimum Order:
1
Product Abstract:
Wanna get a FREE quote now? Just click the below FREE QUOTE button. The experts will get back to you as soon as possible.
- Product Description
- AMP50/40 motar pump Product Abstract:1. Type: Single piston Motar pump2. Brand: iAEG3. Model: AMP50/404. Output: 50L/min, piston type: singleAMP50/40 Single piston motar pump introduce and applications:The RH15W plaster machine has the hose pump as the conveying unit and the min. oilless aircompressor as the unit supplying the compressed air.The RH15W plaster machine has the hose pump as the conveying unit and the min. oilless aircompressor as the unit supplying the compressed air.The RH15W plaster machine has the hose pump as the conveying unit and the min. oilless aircompressor as the unit supplying the compressed air.? Shotcrete/concrete spraying/gunite for tunnels,hydro-power engineering?mines?un -derground engineering, civil engineering and slope stabilization,etc.? Artificial soil seeding for no soil surface, such as rock, sand, and for no fertility soil surface.mortar pump is suitable for pumping and spraying the wet ready-mixed mortar witch is pumpable, such as Cement mortars, Lime plasters, Gypsum plasters, Masonry mortars, Insulating plasters, Self-leveling floor screeds, etc.mortar pump is suitable for pumping and spraying the wet ready-mixed mortar witch is pumpable, such as Cement mortars, Lime plasters, Gypsum plasters, Masonry mortars, Insulating plasters, Self-leveling floor screeds, etc.mortar pump is suitable for pumping and spraying the wet ready-mixed mortar witch is pumpable, such as Cement mortars, Lime plasters, Gypsum plasters, Masonry mortars, Insulating plasters, Self-leveling floor screeds, etc.mortar pump is suitable for pumping and spraying the wet ready-mixed mortar witch is pumpable, such as Cement mortars, Lime plasters, Gypsum plasters, Masonry mortars, Insulating plasters, Self-leveling floor screeds, etcmortar pump is suitable for pumping and spraying the wet ready-mixed mortar witch is pumpable, such as Cement mortars, Lime plasters, Gypsum plasters, Masonry mortars, Insulating plasters, Self-leveling floor screeds, etc.AMP50/40 motar pump with single cylinder and single acting is widely used for its convenient maintenance, high working pressure and high efficiency, working reliability, compact structure etc.It can be used not only for grouting cement mortar and sand mortar, combined with accessories such as compressor and spraying gun, it is also ideal equipment applied in spraying.It is widely used for grouting in mine gallery, rail and road tunnel, hydropower construction, slope consolidation, underground engineering, subway and civil engineering etc.AMP50/40 Single piston motar pump Features:·Single piston single acting·Switch by ball valve·Mechanical transmission, lower failure rate·Compact structure, convenient for maintainingAMP50/40 Single piston motar pump Technical Data:
Cylinder Dia φ90 mm Output 50 L/min Rated Working Pressure 4 Mpa (40bar, 580psi) Piston stroke 85 mm Piston Speed 95 /min Inlet diameter 75 mm Outlet diameter 50 mm Max.Aggregate.size 5 mm Cement : Sand ≥1:3 Dimension 1610×1024×900 mm Weight 300 kg Power unit 5.5 Kw(Electric) / 10hp(Diesel) Note?Single or Double Passageway. Skid or Tyre A.E.G motar pump has the following different types:Plaster Machine AMP-15W;Piston motar pump includes Single piston motar pump AMP50/40 and double-cylinder motar pump AMP60/50;Dry-mixed motar spraying machine AMP-30D;Wet-mixed motar spraying machine AMP-30W and AMP-38W.
